供應DAYTON電機, 馬達(1LPV4, 1LPV4A, 1L476)
|
型號︰ | 1LPV4, 1LPV4A |
品牌︰ | DAYTON |
原產地︰ | 美國 |
單價︰ | - |
最少訂量︰ | - |
|
|
|
|
|
Technical Specs:
- Item: DC Gearmotor
- Voltage: 12VDC
- Shaft Orientation: Parallel
- Reversible Shaft Output: No
- Shaft: Single Output
- Nameplate RPM: 39
- Max. Torque: 26 in.-lb.
- Overhung Load: 50 lb.
- Input HP: 1/30
- Gear Ratio: 62:1
- Full Load Amps: 2.10
- Insulation Class: F
- Enclosure: TENV
- Thermal Protection: None
- Max. Ambient Temp.: 40 Degrees C
- Rotation: Reversible
- Mounting: All Position
- Motor Type: Permanent Magnet DC
- Length Less Shaft: 5-5/8"
- Overall Length: 6-3/8"
- Keyway Size: Flat
- Bearings: Porous Bronze Sleeve on Case, Ball on Motor
- Lubrication: Grease Filled
- Brushes: Externally Replaceable
- Finish: Unpainted
- Gear Material: Acetyl/Steel
- Gear Case: Die Cast Zinc
- Seals: O-Ring Type on Output Shaft
- Housing Material: Die Cast Zinc
- Standards: cRUus
- Replacement Brushes: 6YHY4
- RPM Range: 31 to 50
|
|
|
|
產品規格︰ | 型號: 1LPV4, 1LPV4A (替代舊型號1L476) |
主要市場︰ | 業務QQ: 2543525125, 2054518018, 532560858. |
|
|
產品圖片
|
DAYTON電機, 馬達, 型號: 1LPV4A
DAYTON電機, 馬達, 型號: 1LPV4A
微店, 掃一掃.
DAYTON電機, 馬達, 型號: 1LPV4A
DAYTON電機, 馬達, 型號: 1LPV4
DAYTON電機, 馬達, 型號: 1LPV4
DAYTON電機, 馬達, 型號: 1LPV4
DAYTON電機, 馬達, 型號: 1LPV4
|
|
|
|
|
