TECHNICAL SPECS:

• Item: DC Gearmotor
• Voltage: 90VDC
• Shaft Orientation: Parallel
• Reversible Shaft Output: No
• Nameplate RPM: 62
• Max. Torque: 235 in.-lb.
• Overhung Load: 235 lb.
• Input HP: 1/4
• Gear Ratio: 29:1
• Full Load Amps: 2.51
• Enclosure: TENV
• Thermal Protection: None
• Max. Ambient Temp.: 40 Degrees C
• Rotation: Reversible

• Mounting: All Position
• Motor Type: Permanent Magnet DC
• Length Less Shaft: 12-1/8"
• Overall Length: 13-5/8"
• Bearings: Needle Throughout with Thrust Balls on Case, Ball on Motor
• Lubrication: Permanent Heavy Fluid Gear Oil
• Brushes: Externally Replaceable
• Gear Material: Hardened Steel
• Gear Type: Helical and Spur
• Gear Case: Die Cast Aluminum
• Seals: Spring Loaded Lip Type on Input and Output Shaft
• Housing Material: Die Cast Aluminum
• Replacement Brushes: 6YHZ0

產品規格︰ 型號: 2H577, 2H577B, 2H577C
