TECHNICAL SPECS:

• Item: Universal AC/DC Motor
• Motor Application: Universal AC/DC Motor
• Motor Design: Universal AC/DC
• Motor Enclosure Design: Open
• HP: 1/2
• Nameplate RPM: 10,000
• Frame: Non-Standard
• Voltage: 115
• Hz: 60
• Phase: 1
• Full Load Amps: 6.3
• Motor Mounting Type: Hole
• Motor Mounting Position: All Angle
• Mounting Holes: (4) #10-32
• O.C. Mounting: 2 x 2-13/16"

• Motor Thermal Protection: None
• Ins. Class: A
• Motor Service Factor: 1.00
• Motor Bearings: Ball
• Max. Ambient Temp.: 40 Degrees C
• Motor Shaft Rotation: CCWSE
• Shaft Dia.: 3/8"
• Shaft Length: 1-1/4"
• Overall Length: 7-7/16"
• Length Less Shaft: 6-3/16"
• Body Dia.: 3-3/4 x 3-1/2"
• Average Brush Life: 300 hr.
• Application: Used in Appliances, Power Tools, Outdoor Equipment, Food Processing Equipment, Gearmotors, Blowers, Pumps and Other Applications Where High Horsepower Output and Small Size are Required
• RPM Range: Over 3600

产品规格︰ 型号: 2M145
