产品描述

泵用电机.

Technical Specs:

• Item: Carbonator Pump Motor
• Motor Application: Pumps
• Motor Sub Application: Carbonator Pumps
• Motor Design: Split-Phase
• Motor Enclosure Design: Open Dripproof
• HP: 1/2
• Nameplate RPM: 1725
• Frame: 48Y
• Voltage: 120/240
• Hz: 60/50
• Phase: 1
• Full Load Amps: 7.2/3.6

• Motor Mounting Type: Rigid Base
• Motor Thermal Protection: Auto
• Insulation Class: B
• Service Factor: 1.0
• Bearings: Ball
• Max. Ambient Temp.: 40 Degrees C
• Motor Shaft Rotation: CW/CCW
• Overall Length: 8-3/4"
• Shaft Dia.: 5/8"
• Shaft Length: 1-1/2"
• RPM Range: 1701-1800

产品规格︰ 型号: 5KH36MNA445AX

主要市场︰ 业务QQ: 2543525125, 2054518018, 532560858.

产品图片
