供应AMETEK LAMB ELECTRIC真空马达, 电机(116420-13)

供应AMETEK LAMB ELECTRIC真空马达, 电机(116420-13)

型号︰116420-13

品牌︰AMETEK LAMB

原产地︰美国

单价︰-

最少订量︰-

现在查询

产品描述

Technical Specs:

  • Item: Vacuum Motor
  • Motor/Blower Type: Bypass
  • Discharge: Tangential
  • Blower Stages: 2
  • Number of Speeds: 1
  • Motor Enclosure Design: Open
  • CFM @ 2-In. Orifice: 108.0
  • Vacuum (H2O Sealed): 87.5
  • Voltage: 240
  • Hz: 60/50
  • Phase: 1
  • Max. Amps: 4.4
  • Max. Air Watts: 317
  • Motor Mounting Type: Lug
  • Motor Design: Universal AC/DC
  • Motor Mounting Position: All Angle
  • Thermal Protection: None
  • Insulation Class: A
  • Bearings: Ball
  • Ambient Temperature: 40 Degrees C
  • Body Dia.: 5.7"
  • Overall Height: 6-15/16"
  • Mounting Brackets: Thermoset
  • Duty: Intermittent
  • Average Life: 500 hr.
  • Standards: UL Recognized (E47185), CSA Certified (LR31393)
  • Replacement Brushes: Mfr. No. 833378-50

产品规格︰ 型号: 116420-13

主要市场︰ 业务QQ: 2543525125, 2054518018, 532560858.

产品图片
