Technical Specs:
- Item: DC Gearmotor
- Voltage: 90VDC
- Shaft Orientation: Parallel
- Reversible Shaft Output: No
- Nameplate RPM: 109
- Max. Torque: 27 in.-lb.
- Overhung Load: 150 lb.
- Input HP: 1/20
- Gear Ratio: 17:1
- Full Load Amps: 0.62
- Enclosure: TENV
- Thermal Protection: None
- Max. Ambient Temp.: 40 Degrees C
- Rotation: Reversible
- Mounting: All Position
- Motor Type: DC
- Length Less Shaft: 8-5/8"
- Overall Length: 10-1/8"
- Bearings: Needle Roller and Thrust Balls on Case, Ball on Motor
- Lubrication: Permanent Heavy Fluid Gear Oil
- Brushes: Externally Replaceable
- Gear Material: Hardened Steel
- Gear Type: Helical and Spur
- Gear Case: Die Cast Aluminum
- Seals: Spring Loaded Lip Type on Input and Output Shaft
- Housing Material: Die Cast Aluminum
- Replacement Brushes: 6YHY3
- RPM Range: 100 to 150
产品规格︰
型号: 4Z131, 4Z131C, 4Z131B, 4Z131A
