产品描述

Technical Specs:

• Item: DC Gearmotor
• Type: Right Angle
• Voltage Rating: 90VDC
• Phase: DC
• Shaft Orientation: Right Angle
• Reversible Shaft Output: No
• Shaft: Right Hand Output
• Nameplate RPM: 6.0
• Full Load Torque (In.-Lbs.): 177.0
• Overhung Load (Lb.): 100
• Input HP: 1/20
• Gear Ratio: 275:1
• Full Load Amps: 0.59
• Insulation Class: F
• Enclosure: TENV
• Thermal Protection: None
• Ambient (C): 40

• Rotation: Reversible
• Mounting: All Position
• Motor Type: Permanent Magnet
• Shaft Dimensions (In.): 1/2 x 1 5/8
• Keyway (In.): #404 Woodruff Key
• Bearings: Porous Bronze Sleeve on Case, Ball on Motor
• Lubrication: Grease Filled
• Lubrication Quantity (Qt.): 3.2 oz.
• Brushes: Externally Replaceable
• Finish: Unpainted
• Housing: Zinc Die Cast
• Gear Case: Zinc Die Cast
• Gears: Input Gear Steel, Worm Hardened Steel, Output Gear Cast Iron
• Seals: Lip Type on Output Shaft
• Agency Compliance: cRUus
• Replacement Brushes: 6YHY6
• RPM Range: 0 to 15

产品规格︰ 型号: 1LRA9(替代旧型号4Z724, 4Z724A)

主要市场︰ 业务QQ: 2543525125, 2054518018, 532560858.

产品图片
