产品描述
| Item |
|
DC Gearmotor |
| Type |
|
Parallel Shaft |
| Voltage Rating |
|
90VDC |
| Phase |
|
DC |
| Shaft Orientation |
|
Parallel |
| Reversible Shaft Output |
|
No |
| Shaft |
|
Single Output |
| Nameplate RPM |
|
11 |
| Full Load Torque (In.-Lbs.) |
|
50.0 |
| Overhung Load (Lb.) |
|
50 |
| Input HP |
|
1/30 |
| Gear Ratio |
|
273:1 |
| Full Load Amps |
|
0.35 |
| Insulation Class |
|
F |
| Enclosure |
|
TENV |
| Thermal Protection |
|
None |
| Ambient (C) |
|
40 |
| Rotation |
|
Reversible |
| Mounting |
|
All Position |
| Motor Type |
|
Permanent Magnet |
| Length Less Shaft (In.) |
|
6-1/8 |
| Shaft Dimensions (In.) |
|
5/16 x 3/4 |
| Keyway (In.) |
|
Flat |
| Bearings |
|
Porous Bronze Sleeve on Case, Ball on Motor |
| Lubrication |
|
Grease Filled |
| Lubrication Quantity (Qt.) |
|
3.2 oz. |
| Brushes |
|
Externally Replaceable |
| Finish |
|
Unpainted |
| Housing |
|
Zinc Die Cast |
| Gear Case |
|
Zinc Die Cast |
| Gears |
|
Acetyl/Steel |
| Seals |
|
O-Ring Type on Output Shaft |
| Agency Compliance |
|
cRUus |
| Replacement Brushes |
|
6YHY3 |
| RPM Range |
|
0 to 15 |
产品规格︰
型号: 1LPW1, 1LPW1A (替代旧型号4Z535, 4Z535A)
